Arthritis Treatment Data

Data from Koch & Edwards (1988) from a double-blind clinical trial investigating a new treatment for rheumatoid arthritis.

data("Arthritis")

Format

A data frame with 84 observations and 5 variables.

ID

patient ID.

Treatment

factor indicating treatment (Placebo, Treated).

Sex

factor indicating sex (Female, Male).

Age

age of patient.

Improved

ordered factor indicating treatment outcome (None, Some, Marked).

References

G. Koch & S. Edwards (1988), Clinical efficiency trials with categorical data. In K. E. Peace (ed.), Biopharmaceutical Statistics for Drug Development, 403–451. Marcel Dekker, New York.

M. Friendly (2000), Visualizing Categorical Data. SAS Institute, Cary, NC.

Source

Michael Friendly (2000), Visualizing Categorical Data: http://euclid.psych.yorku.ca/ftp/sas/vcd/catdata/arthrit.sas

Examples

data("Arthritis")
art <- xtabs(~ Treatment + Improved, data = Arthritis, subset = Sex == "Female")
art
#>          Improved
#> Treatment None Some Marked
#>   Placebo   19    7      6
#>   Treated    6    5     16

mosaic(art, gp = shading_Friendly)

mosaic(art, gp = shading_max)
