Plot methods for spatial data with attributes

spplot.Rd

Lattice (trellis) plot methods for spatial data with attributes

Usage

spplot(obj, ...)
spplot.grid(obj, zcol = names(obj), ..., names.attr, scales = list(draw = FALSE),
 xlab = NULL, ylab = NULL, aspect = mapasp(obj,xlim,ylim),
 panel = panel.gridplot, sp.layout = NULL, formula, xlim = bbox(obj)[1, ],
 ylim = bbox(obj)[2, ], checkEmptyRC = TRUE, col.regions = get_col_regions())
spplot.polygons(obj, zcol = names(obj), ..., names.attr, scales = list(draw = FALSE),
 xlab = NULL, ylab = NULL, aspect = mapasp(obj,xlim,ylim),
 panel = panel.polygonsplot, sp.layout = NULL, formula, xlim = bbox(obj)[1, ],
 ylim = bbox(obj)[2, ], col.regions = get_col_regions())
spplot.points(obj, zcol = names(obj), ..., names.attr, scales = list(draw = FALSE),
 xlab = NULL, ylab = NULL, aspect = mapasp(obj,xlim,ylim),
 panel = panel.pointsplot, sp.layout = NULL, identify = FALSE, formula,
 xlim = bbexpand(bbox(obj)[1, ], 0.04), ylim = bbexpand(bbox(obj)[2, ], 0.04),
 edge.col = "transparent", colorkey = FALSE, col.regions = get_col_regions())
mapLegendGrob(obj, widths = unit(1, "cm"), heights = unit(1, "cm"),
  fill = "black", just = "right")
sp.theme(set = FALSE, regions = list(col = bpy.colors(100)), ...)
layout.north.arrow(type = 1)
layout.scale.bar(height = 0.05)
spplot.locator(n = 512, type = "n", ...)
set_col_regions(value)
get_col_regions()

Arguments

obj

object of class extending Spatial-class

zcol

character; attribute name(s) or column number(s) in attribute table

names.attr

names to use in panel, if different from zcol names

scales

scales argument to be passed to Lattice plots; use list(draw = TRUE) to draw axes scales; see xyplot for full options

...

other arguments passed to levelplot (grids, polygons) or xyplot (points)

xlab

label for x-axis

ylab

label for y-axis

aspect

aspect ratio for spatial axes; defaults to "iso" (one unit on the x-axis equals one unit on the y-axis) but may be set to more suitable values if the data are e.g. if coordinates are latitude/longitude

panel

depending on the class of obj, panel.polygonsplot (for polygons or lines), panel.gridplot (grids) or panel.pointsplot (points) is used; for further control custom panel functions can be supplied that call one of these panel functions, but do read below how the argument sp.layout may help

sp.layout

NULL or list; see notes below

identify

if not FALSE, identify plotted objects (currently only working for points plots). Labels for identification are the row.names of the attribute table row.names(as.data.frame(obj)). If TRUE, identify on panel (1,1); for identifying on panel i,j, pass the value c(i,j)

formula

optional; may be useful to plot a transformed value. Defaults to z~x+y for single and z~x+y|name for multiple attributes; use e.g. exp(x)~x+y|name to plot the exponent of the z-variable

xlim

numeric; x-axis limits

ylim

numeric; y-axis limits

edge.col

color of symbol edge

colorkey

if FALSE, use symbol key; if TRUE, use continuous, levelplot-like colorkey; if list, follow syntax of argument colorkey in levelplot (see below for an example)

widths

width of grob

heights

heights of grob

fill

fill color of grob

just

grob placement justification

set

logical; if TRUE, trellis.par.set is called, else a list is returned that can be passed to trellis.par.set()

regions

color ramp for the theme

height

height of scale bar; width is 1.0

n

see locator

type

see locator

checkEmptyRC

logical; if TRUE, a check is done to see if empty rows or columns are present, and need to be taken care of. Setting to FALSE may improve speed.

col.regions

vector with fill colours; in case the variable to be plotted is a factor, this vector should have length equal to the number of factor levels

value

vector with color values, default for col.regions

Value

spplot returns a lattice plot of class "trellis", if you fail to "see" it, explicitly call print(spplot(...)). If identify is TRUE, the plot is plotted and the return value is a vector with row names of the selected points.

spplot.locator returns a matrix with identified point locations; use trellis.focus first to focus on a given panel.

get_col_regions returns the default value for col.regions

Methods

obj = "SpatialPixelsDataFrame"

see spplot

obj = "SpatialGridDataFrame"

see spplot

obj = "SpatialPolygonsDataFrame"

see spplot

obj = "SpatialLinesDataFrame"

see spplot

obj = "SpatialPointsDataFrame"

see spplot

Note

Missing values in the attributes are (currently) not allowed.

spplot.grid, spplot.polygons and spplot.points are S4 methods for spplot; see spplot-methods.

Useful arguments that can be passed as ... are:

layout

integer; for the layout of panels (cols,rows)

pretty

logical; choose colour breaks at pretty numbers?

at

specify at which values colours change

as.table

logical; start drawing panels upper-left instead of lower-left

page

to add marks to each plotted page

for useful values see the appropriate documentation of xyplot (in case of points), and levelplot (otherwise).

If obj is of SpatialPointsDataFrame, the following options are useful to pass:

key.space

character: "bottom", "right", "left" or "right" to denote key location, or list: see argument key in the help for xyplot what the options are

legendEntries

character; array with key legend (text) entries; suitable defaults obtained from data

cuts

number of cuts, or, for objects of class SpatialPointsDataFrame only, the actual cuts to use

do.log

logical; if TRUE use log-linear scale to divide range in equal cuts, else use a linear scale if cuts is only number of cuts

pch

integer; plotting character to use; defaults to 16 if fill is TRUE, else 1

cex

numeric; character expansion, proportional to default value of 1

fill

logical; use filled circles?

layout.north.arrow and layout.scale.bar can be used to set a north arrow or scale bar.

The sp.layout argument is either a single layout item, or a list with one or more layout items. A layout item is one of

  • a list with one or more Spatial* objects, along with style arguments like col, lty, pch, fill etc.

  • a list with its first argument the layout function or the name of the layout function to be called: sp.points for SpatialPoints, sp.polygons for SpatialPolygons object, sp.lines for a SpatialLines object, and sp.text for text to place. The second argument contains the object (or text) to be plotted; remaining arguments are passed to the corresponding panel.* functions.

The order of items in sp.layout matters; objects are drawn in the order they appear. With respect to obj, default plot order and precedence of sp.layout items is as follows: for points and lines, sp.layout items are drawn over (after) obj; for grids and polygons, sp.layout items are drawn behind (before) obj. Transparency may further help making multiple things visible. Adding a first argument to a layout item overrides its default plotting order with respect to obj:

Special control elements of sp.layout items:

first

logical; should the layout item be drawn before the obj (TRUE), or after (FALSE)? This overrides the default order (points and lines in front, polygons and grids behind).

which

integer; controls to which panel a layout item should be added. If which is present in the main, top-level list it applies to all layout items; in sub-lists with layout items it denotes the (set of) panel(s) in which the layout item should be drawn. Without a which item, layout items are drawn in each panel.

sp.theme returns a lattice theme; use, after loading package lattice, the command trellis.par.set(sp.theme()) after a device is opened or changed to make this work. Currently, this only sets the colors to bpy.colors.

If the attributes to be plotted are of type factor, spplot tries to create a legend that reflects this. In this case, the color ramp passed needs to be of the same length as the number of factor levels. The factor levels are derived from the first map; subsequent factors with different factor levels result in an error.

References

https://edzer.github.io/sp/

See also

xyplot, levelplot, panel.identify to identify objects

Author

Edzer Pebesma, edzer.pebesma@uni-muenster.de

Examples

library(lattice)
trellis.par.set(sp.theme()) # sets bpy.colors() ramp
demo(meuse, ask = FALSE, echo = FALSE)
l2 = list("SpatialPolygonsRescale", layout.north.arrow(), offset = c(181300,329800),
  scale = 400)
l3 = list("SpatialPolygonsRescale", layout.scale.bar(), offset = c(180500,329800),
  scale = 500, fill=c("transparent","black"))
l4 = list("sp.text", c(180500,329900), "0")
l5 = list("sp.text", c(181000,329900), "500 m")

spplot(meuse, c("ffreq"), sp.layout=list(l2,l3,l4,l5), col.regions= "black",
  pch=c(1,2,3), key.space=list(x=0.1,y=.95,corner=c(0,1)))

spplot(meuse, c("zinc", "lead"), sp.layout=list(l2,l3,l4,l5, which = 2),
  key.space=list(x=0.1,y=.95,corner=c(0,1)))

# plotting factors:
meuse$f = factor(sample(letters[6:10], 155, replace=TRUE),levels=letters[1:10])
meuse$g = factor(sample(letters[1:5], 155, replace=TRUE),levels=letters[1:10])
spplot(meuse, c("f","g"), col.regions=bpy.colors(10))


if (require(RColorBrewer)) {
  spplot(meuse, c("ffreq"), sp.layout=list(l2,l3,l4,l5),
    col.regions=brewer.pal(3, "Set1"))
}
#> Loading required package: RColorBrewer


meuse.grid$g = factor(sample(letters[1:5], 3103, replace=TRUE),
  levels=letters[1:10])
meuse.grid$f = factor(sample(letters[6:10], 3103, replace=TRUE),
  levels=letters[1:10])
spplot(meuse.grid, c("f","g"), col.regions=bpy.colors(10))


# example modifying colorkey for points:
spplot(meuse["dist"], colorkey = list(
  right = list( # see ?levelplot in package trellis, argument colorkey:
    fun = draw.colorkey,
    args = list(
      key = list(
        at = seq(0, 1, .1), # colour breaks
        col = bpy.colors(11), # colours
        labels = list(
          at = c(0, .2, .4, .6, .8, 1),
          labels = c("0x", "20x", "40x", "60x", "80x", "100x")
        )
      )
    )
  )
))

l6 = list(meuse.grid["dist"], col = grey(seq(.5,.9,length.out=10)))
spplot(meuse, c("zinc", "lead"), sp.layout = l6)

spplot(meuse, c("zinc", "lead"),
  sp.layout = list(meuse.grid, meuse.riv, col = 'grey'))


#  Custom legend placement, taken from
# http://stackoverflow.com/questions/29344692/custom-placement-of-spplot-legend-in-the-map
s <- spplot(meuse.grid[,'dist'], colorkey = list(space = "left", height = 0.4))

args <- s$legend$left$args$key

## Prepare list of arguments needed by `legend=` argument (as described in ?xyplot)
library(lattice) # draw.colorkey
legendArgs <- list(fun = draw.colorkey,
                   args = list(key = args),
                   corner = c(0.05,.75))

## Call spplot() again, this time passing in to legend the arguments
## needed to print a color key
spplot(meuse.grid[,'dist'], colorkey = FALSE,
       legend = list(inside = legendArgs))
